Type T1B
vlaksmeernippel
- zeshoekige kop en stelring, Hex grootte 15mm
- Recht type A/180°
- Standaardtypes volgens de DIN-norm zijn gemaakt van staal en zijn verzinkt en gepassiveerd en voorzien van een cilindrische schroefdraad
- Voor andere materialen of samenstellingen ; zie tabel of vraag ons gerust om meer informatie
- GW = schroefdraad
- L1 = algemene lengte
- L2 = lengte schroefdraad
- L3 = lengte nek
- SW = HEX grootte
- (alle eenheden in mm, schroefdraadmeting of inches)
|
GW M 6 x 1.0 |
|
Ref.- No.: |
|
|
|||
|
L1 |
L2 |
L3 |
SW |
Steel (staal) |
Brass (messing) |
V2A (inox) |
V4A (inox) |
|
16 |
6 |
6 |
15mm HEX |
4601504 |
4611504 |
|
|
|
GW M 8 x 1.0 |
|
Ref.- No.: |
|
|
|||
|
L1 |
L2 |
L3 |
SW |
Steel |
Brass |
V2A (inox) |
V4A (inox) |
|
16 |
6 |
6 |
15mm HEX |
4601507 |
4611507 |
|
|
|
GW M 8 x 1.25 |
|
Ref.- No.: |
|
|
|||
|
L1 |
L2 |
L3 |
SW |
Steel |
Brass |
V2A (inox) |
V4A (inox) |
|
16 |
6 |
6 |
15mm HEX |
4601508 |
4611508 |
|
|
|
GW M 10 x 1.0 |
|
Ref.- No.: |
|
|
|||
|
L1 |
L2 |
L3 |
SW |
Steel |
Brass |
V2A (inox) |
V4A (inox) |
|
16 |
6 |
6 |
15mm HEX |
4601509 |
4611509 |
4621509 |
|
|
GW M 10 x 1.25 |
|
Ref.- No.: |
|
|
|||
|
L1 |
L2 |
L3 |
SW |
Steel |
Brass |
V2A (inox) |
V4A (inox) |
|
16 |
6 |
6 |
15mm HEX |
4601511 |
4611511 |
|
|
|
GW M 12 x 1.5 |
|
Ref.- No.: |
|
|
|||
|
L1 |
L2 |
L3 |
SW |
Steel |
Brass |
V2A (inox) |
V4A (inox) |
|
16 |
6 |
6 |
15mm HEX |
4601514 |
4611514 |
4621514 |
|
|
GW M 12 x 1.75 |
|
Ref.- No.: |
|
|
|||
|
L1 |
L2 |
L3 |
SW |
Steel |
Brass |
V2A (inox) |
V4A (inox) |
|
16 |
6 |
6 |
15mm HEX |
4601516 |
|
|
|
|
GW G 1/8, 1/8 - 28 BSPP |
|
Ref.- No.: |
|
|
|||
|
L1 |
L2 |
L3 |
SW |
Steel |
Brass |
V2A (inox) |
V4A (inox) |
|
16 |
6 |
6 |
15mm HEX |
4601561 |
4611561 |
4621561 |
4641561 |
|
GW G 1/4, 1/4 - 19 BSPP |
|
Ref.- No.: |
|
|
|||
|
L1 |
L2 |
L3 |
SW |
Steel |
Brass |
V2A (inox) |
V4A (inox) |
|
16 |
6 |
6 |
15mm HEX |
4601562 |
4611562 |
4621562 |
4641562 |
|
GW G 3/8, 3/8 - 19 BSPP |
|
Ref.- No.: |
|
|
|||
|
L1 |
L2 |
L3 |
SW |
Steel |
Brass |
V2A (inox) |
V4A (inox) |
|
16 |
6 |
6 |
15mm HEX |
5372717 |
|
|
|
|
GW 1/8" - 27 NPT/PTF |
|
Ref.- No.: |
|
|
|||
|
L1 |
L2 |
L3 |
SW |
Steel |
Brass |
V2A (inox) |
V4A (inox) |
|
16 |
6 |
6 |
15mm HEX |
|
|
|
4641567 |
|
GW 1/4" - 28 NF/UNF/SAE |
|
Ref.- No.: |
|
|
|||
|
L1 |
L2 |
L3 |
SW |
Steel |
Brass |
V2A (inox) |
V4A (inox) |
|
16 |
6 |
6 |
15mm HEX |
4601537 |
|
|
|
|
GW 3/8" - 24 NF/UNF/SAE |
|
Ref.- No.: |
|
|
|||
|
L1 |
L2 |
L3 |
SW |
Steel |
Brass |
V2A (inox) |
V4A (inox) |
|
16 |
6 |
6 |
15mm HEX |
4601539 |
|
|
|
