Productomschrijving: verlengnippel of verloopstuk conisch BSP of metrisch Toepassingsgebied: • centrale smering vet of olie • centrale smeersystemen voor vaste en mobiele toepassingen • hydrauliekleidingwerk Materiaal: staal, chroom vrij, gegalvaniseerd. In RVS roest vast staal (inox) ook verkrijgbaar. Het is ook mogelijk een smeerleiding onmiddellijk te connecteren op een verloopstuk. |
| Artikel Nr. | G | G1 | L | L1 | SW |
| FI.526.M6X1-M6X1-20 | M 6 x 1 | M 6 x 1 | 57.5 | 7.5 | 9 |
| FI.526.M6X1-M6X1-57 | M 6 x 1 | M 6 x 1 | 20 | 7.5 | 9 |
| FI.526.M6X1-M8X1-18 | M 6 x 1 | M 8 x 1 | 18 | 8 | 11 |
| FI.526.M6X1-M10X1-23 | M 6 x 1 | M 10 x 1 | 23 | 10 | 13 |
| FI.526.M6X1-R02-23 | M 6 x 1 | Rp 1/8 BSP | 23 | 10 | 13 |
| FI.526.M8X1-M8X1-18 | M 8 x 1 | M 8 x 1 | 18 | 8 | 11 |
| FI.526.M8X1-M8X1-32 | M 8 x 1 | M 8 x 1 | 32 | 22 | 11 |
| FI.526.M8X1-M8X1-62,5 | M 8 x 1 | M 8 x 1 | 62.5 | 52.5 | 11 |
| FI.526.M8X1.25-M8X1.25-23 | M 8 X 1.25 | M 8 X 1.25 | 20 | 7 | 11 |
| FI.526.M8X1.25-M8X1.25-32 | M 8 X 1.25 | M 8 X 1.25 | 32 | 22 | 11 |
| FI.526.M8X1-R02-23 | M 8 X 1 | Rp 1/8 BSP | 23 | 12 | 13 |
| FI.526.M8X1-R04-22 | M 8 X 1 | Rp 1/4 BSP | 22 | 8 | 17 |
| FI.526.M8X1-M10X1-23 | M 8 x 1 | M 10 x 1 | 23 | 12 | 13 |
| FI.526.M10X1-M8X1-18 | M10 x 1 | M 8 x 1 | 18 | 8 | 11 |
| FI.526.M10X1-M10X1-18 | M10 x 1 | M 10 x 1 | 18 | 7 | 13 |
| FI.526.M10X1-M10X1-35 | M10 x 1 | M10 x 1 | 35 | 24 | 13 |
| FI.526.M10X1-M10X1-40 | M10 x 1 | M10 x 1 | 40 | 29 | 13 |
| FI.526.M10X1-M10X1-50 | M10 x 1 | M10 x 1 | 50 | 39 | 13 |
| FI.526.R02-M10X1-18 | R 1/8 BSP | M 10 x 1 | 18 | 7 | 13 |
| FI.526.R02-R02-18 | R 1/8 BSP | Rp 1/8 BSP | 18 | 7 | 13 |
| FI.526.R02-M8X1-18 | R 1/8 BSP | M8 x 1 | 18 | 7 | 13 |
| FI.526.R02-R02-30 | R 1/8 BSP | Rp 1/8 BSP | 30 | 18 | 13 |
| FI.526.R02-R02-35 | R 1/8 BSP | Rp 1/8 BSP | 35 | 23 | 13 |
| FI.526.R02-R02-41 | R 1/8 BSP | R 1/8 BSP | 41 | 29 | 13 |
| FI.526.R02-R02-45 | R 1/8 BSP | R 1/8 BSP | 45 | 33 | 13 |
| FI.526.R02-R02-50 | R 1/8 BSP | R 1/8 BSP | 50 | 38 | 13 |
| FI.526.R02-R04-22 | R 1/8 BSP | Rp 1/4 BSP | 22 | 8 | 17 |
| FI.526-R04-M10X1-20 | R 1/4 BSP | M 10 x 1 | 20 | 9 | 17 |
| FI.526-R04-R02-20 | R 1/4 BSP | Rp 1/8 BSP | 20 | 9 | 17 |
| FI.526.R04-R06-27 | R 1/4 BSP | Rp 3/8 BSP | 27 | 11 | 22 |
| FI.526.R04-R04-25 | R 1/4 BSP | Rp 1/4 BSP | 25 | 17 | 17 |
| FI.526.R04-R04-85 | R 1/4 BSP | R 1/4 BSP | 85 | 71 | 17 |
| FI.526.R02NPT-R02NPT-20 | 1/8 NPT | 1/8 NPT | 20 | 9 | 1/2 |
| FI.526.R02NPT-R02NPT-30 | 1/8 NPT | 1/8 NPT | 30 | 18 | 1/2 |
| FI.526.R04UNF-R02-23 | 1/4-28 UNF | 1/8 BSP | 23 | 12 | 1/2 |
| FI.526.M10X1.5-M10X1-23 | M 10 x 1.5 | M 10 x 1 | 23 | 12 | 13 |
| FI.526.M10X1-R04-22 | M 10 x 1 | Rp 1/4 BSP | 22 | 8 | 17 |
| FI.526.M10X1-R02-18 | M 10 x 1 | Rp 1/8 BSP | 18 | 7 | 13 |
